FTTH Drop Cable Production: Step-by-Step Manufacturing Process
Surprising fact: over 70% of new broadband deployments in the U.S. now depend on fiber networks that need tight manufacturing control to achieve required performance.
Shanghai Weiye OFC Equipment manages end-to-end compact fiber unit manufacturing, from choosing brand fibers like Fujikura® or Corning SMF-28e to complete test reports that deliver 100% QA.
Our drop cable designs fit aerial, underground, and direct-buried installation, with low-smoke zero-halogen (LSZH), polyvinyl chloride (PVC), and polyethylene (PE) jacket options and core counts from 1–4 cores. We supply single-mode OS1/OS2 and multimode OM2–OM4 grades plus G.652D and ITU-T G.657 variants, Pantone sheath colors, and custom logo printing.
Automated machines and precision equipment stabilize line speed and keep repeatability high. Typical lead times are 4–5 days for orders under 100 km and 7–10 days for < 500 km, with an min. order of 1 km and warranty for free replacement on quality issues.
Keep reading to understand how materials plus testing and support help reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment provides end-to-end manufacturing and lab testing for United States projects.
- A range of jacket options and fiber grades cover different install environments.
- Automated production lines provide stable quality and stable optical performance.
- Quick lead times, low MOQ, and recognized brand fibers help plan procurement reliably.
- Complete reports and warranty support product reliability and compliance documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment provides tailored drop solutions with full test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment combines purpose-built equipment with stringent material control. We offer custom builds and services for residential/MDU deployments. Every order includes 100% quality assurance and full test reports.
Our lab runs high-temperature, salt spray, and vibration tests to validate durability. Jacket options cover LSZH, PVC, and PE. Designs offer bow-type flat and figure-8/self-supporting styles and use brand fibers such as Fujikura and Corning® SMF-28e.
- Documented line control and production checks for fully auditable shipments.
- Engineering support for requirements, pilots, and scaling.
- Modern fixturing and calibration reduce variability so every cable meets carrier standards.
FTTH cable production
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with disciplined test flows.
Selecting Optical Fiber and Brands
We select Fiber coloring machine to minimum bend radius, attenuation, and deployment type. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning® SMF-28e are offered to satisfy sourcing standards.
Strength member integration
Strength members employ dielectric FRP or galvanized steel wire. FRP is preferred where non-conductive runs are required. Steel wire provides tensile strength for longer aerial spans and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for indoor flame safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Closed-loop control of extruder temperature and capstan speed stabilizes line speed and dimensional tolerances.
| Component | FRP | Steel wire |
|---|---|---|
| Use case | Electrical isolation | High-tension aerial runs |
| Key benefit | Light, non-corrosive | High strength |
| Installation note | Easier terminations | Requires grounding |
In-Process and Final Testing
Inline geometry and concentricity checks run during manufacturing. Final optical tests verify loss and reflectance. Each order includes a full test report and lab results from high heat, salt fog, and vibration tests to qualify field handling and drop terminations.
Typical lead times are under 100 km in 4–5 days and under 500 km in 7–10 days. Lot records and first-article approvals provide traceability and compliance for U.S. programs.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a focused portfolio of drop designs that suit both tight indoor routes and exposed aerial spans. Each option pairs tested materials with geometry tuned for field termination and consistent optical performance.
The flat bow-type drop minimizes footprint for risers and conduit. It keeps bend loss low for easy routing in hallways and MDUs.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs use a support messenger to carry tensile loads. Choose FRP (dielectric) for electrical isolation or steel wire when bonding/grounding and higher tensile strength are required.
Layouts & Strength Members
We provide dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and unitube flat types balance crush resistance and fiber ribbone line for quick termination.
Indoor/outdoor jackets
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each series is validated for mechanical and optical quality before shipment.
| Design | Application | Strength element | Sheath |
|---|---|---|---|
| Flat bow-type | Indoor risers and MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Overhead spans | Steel wire or FRP | PE |
| Central loose-tube | Higher fiber counts | Dielectric FRP | LSZH/PE |
| Unitube flat | Low-count, easy strip | FRP/Steel | LSZH/PE |
Production line equipment that ensures quality and speed
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and increase throughput for drop patch preparation.
Our production line integrates automated machines that cut/strip drop cords to raise throughput and reduce operator variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Automated cutting and stripping for drop cable patch cords
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise stub lengths. Pneumatic cylinder actuators provide quick, repeatable motion and minimize downtime.
Closed-Loop Control for Repeatability
PLC logic + photoelectric sensors deliver precise positioning and closed-loop control. Inline checks feed control charts so operators can correct trends before defects grow.
| Item | Capability | Benefit |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | ~20 terminals/minute throughput |
| Drive | Cylinder-based | High speed and reliability |
| Material handling | LSZH & PVC; FRP & steel | Accurate stubs, clean terminations |
| Process control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Automated waste ejection and ergonomic feeders keep the line clean.
- Process control plans document calibration and key parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without sacrificing accuracy.
CLX-BPO2 auto-stripping machine capabilities in our line
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to raise output and standardize terminal quality. The unit runs at an approximate cycle time of 1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC/photoelectric control deliver exact detection and repeatable actuation. That control keeps strip and stub lengths within tight tolerances.
Line Speed
Typical operation speed is ~1.5 seconds per cycle. This translates to steady throughput under normal production conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable strip length from 17.5–35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
FRP & Steel Member Handling
The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Customized cutters are offered for non-standard cross-sections to preserve precision.
- Automatic waste ejection and sensor start reduce idle time.
- Small footprint (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg weight simplify cell integration.
- Pneumatic cylinders and closed-loop control boost reliability and lower maintenance interruptions.
| Specification | Value | Why it matters |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | High throughput for production runs |
| Strip lengths (A) | 17.5–35.0 mm | Fits common connector processes |
| Reserved stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power & size | 110–220V, 50W; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 helps our production lines meet volume goals without compromising quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify deployment. We pair concise options with predictable manufacturing windows so your teams get install-ready reels.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1/OS2 plus OM2–OM4 along with G.652D/G.657 variants to align with optics and connector plans.
We Pantone-match sheath colors for fast field ID and consistent asset tags.
Branding and Print Options
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom legends/logos support inventory and warranty tracking.
Length options, packaging, and special structures
Standard reel lengths are 1/2/4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.
| Choice | Common choice | Benefit |
|---|---|---|
| Reel length | 1, 2, or 4 km | Less staging, easier reels |
| Sheath | LSZH, PE, PVC | Indoor/Outdoor fit |
| Structure | Bow-type / Self-supporting | Flexible routing/span |
As a supplier, Shanghai Weiye schedules runs to your plan and delivers documentation that lists final specifications for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
High-temperature, salt spray, and vibration laboratory testing
Our lab conducts high-temperature exposure, salt fog corrosion, and mechanical vibration to qualify materials and assemblies. These tests simulate field stresses for indoor and outdoor use.
100% test reports for every cable
Every fiber optic cable ships with a 100% test report that logs attenuation, return loss, and geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Traceability & Compliance
Lot/batch records link tests to reels/serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection reduce field failures and cut warranty events.
- QA packages include spec confirmation and formatted data for rapid review.
- Ongoing trend analysis drive preventive maintenance and improve long-term reliability.
| Test | Why | Result |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt-fog | Corrosion resistance | Outdoor suitability |
| Vibration | Mechanical robustness | Reduced field failures |
Cost Drivers and Pricing
Budgeting for a drop run starts with fiber and jacket choices and is refined by volume and customization.
Typical prices range broadly—from about $30 to $1,000 per unit—based on fiber grade, jacket chemistry (LSZH, PVC, PE), reel length, and structural design.
Primary Cost Inputs
The primary cost drivers are fiber grade, jacket material, and the chosen structure for deployment.
Self-supporting structures and steel members raise material and labor input. Custom sheath colors/logos/legends add setup and impact pricing on small runs.
How Volume & Options Affect Cost
Longer put-ups and larger volumes reduce unit cost. Small quantities often include setup charges and higher per-unit charges.
- Line changeovers and custom tooling increase lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets over phases.
| Factor | Effect on price | Guidance |
|---|---|---|
| Fiber grade | Large | Right-size spec to budget |
| Sheath material | Medium | Evaluate LSZH vs PE |
| Order length / volume | Large | Consolidate runs to cut unit cost |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align staffing and sites. Predictable schedules reduce downtime and control costs when a rollout is underway.
Production Windows & Capacity
Typical production windows are 4–5 days for < 100 km and 7–10 days for orders under 500 km. We plan capacity to match your rollout milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For tight schedules, we reserve contingency capacity to pull in critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects setup needs such as wire and jacket die adjustments that use startup material and generate scrap.
We review your length and staging plans to choose reel sizes that cut waste and handling. Staggered batches can balance inventory with more frequent small-site deliveries.
Installation Scenarios & Readiness
Site conditions dictate whether a self-supporting aerial, duct pull, or direct-buried run is the right choice for a project.
Aerial, duct, and direct-buried deployment considerations
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with appropriate members to control sag and tension for long-term stability.
Duct installations work best with low-friction sheaths and crush-resistant builds so pulling avoids fiber damage. PE jackets are common for underground and buried paths where moisture resistance matters.
Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor riser/plenum distribution and ONT termination
Indoor riser/plenum routes favor LSZH jackets to meet flame and smoke rules. Flat drop profiles strip cleanly and present controlled stubs for fast ONT terminations.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware fit. Standardized line prep shortens install time and reduces scrap.
| Scenario | Key design | Field note |
|---|---|---|
| Overhead | Self-supporting, steel or FRP | Check tension and messenger hardware |
| Duct | Low-friction jacket, crush resistance | Use pull tape and proper lubricant |
| Direct-buried | PE jacket, moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH with tight-bend support | Maintain bend radius at wall penetrations |
Our approach delivers a consistent installation across indoor/outdoor transitions. That leads to fewer callbacks, faster activations, and stable field performance for your system.
Support from Spec to Service
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements through approved drawings and pre-production builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full reports and traceability to support QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty includes free replacement for confirmed quality issues.
- Coordination of line schedules for expedites and urgent changes.
- Config control so shipped items match agreed specs consistently.
| Support area | Scope | Outcome |
|---|---|---|
| Engineering | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab trials & 100% test reports | Full traceability |
| Service | Fast replace + RCA | Lower downtime |
Conclusion
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We deliver customized FTTH drop solutions that pair material choices with validated manufacturing and lab testing. Every reel includes a 100% test report and documented trials to support field acceptance in the United States.
A hardened production line, including CLX-BPO2 prep assets, cuts variability and shortens turnaround. Our equipment and machines standardize strip and stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to maximize service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Contact Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
